|Hydraulic Pressure:||10-25Mpa||Granulation Rate:||＞50%|
|Way To Control:||Button/Touch Screen/Remote||Special Design:||Heat Sensitive / Wall Adhesive|
tablet granulation machine,
dry granulation equipment
GMP dry granulator is developed with combination of Germany technique. Compared against conventional dry granulator, GMP has much better granulation rate, and it is easier for a thorough cleaning. It is specially designed for pharmaceutical and food industry, which could meet GMP standard.
(1) Vertical feeding instead of conventional horizontal feeding.
(2) Screw feeder feeding the raw material into rollers.
(3) Roller are cantilever installed, which is easy for dissemble and clean.
(4) Vertical layout of two rollers, could avoid raw material dropping because of gravity.
(5) Two level of sifting system could increases granulation rate
(6) The granulator works in closed operation, which avoids dust pollution.
(7) PLC and touch screen as an optional choice
The equipment is suitable in pharmaceutical industry, food Indurtsy, chemical industry, soda ash, fertilizer, feed, plastic additive, cosmetic, synthetic detergent and so on.
Picture of Dry Granulator in Working
