10000KG/H Spin Flash Spray Drying Machine Energy Saving

10000KG/H Spin Flash Spray Drying Machine Energy Saving
10000KG/H Spin Flash Spray Drying Machine Energy Saving

Large Image :  10000KG/H Spin Flash Spray Drying Machine Energy Saving

Product Details:
Place of Origin: China
Brand Name: WELLDONE
Certification: CE, ISO 9001: 2008, ISO 10004
Model Number: LPG-(5-2000)
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: Wooden Case + Plastic Film + Steel Frame
Delivery Time: 30-90Working Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10Sets/Months

10000KG/H Spin Flash Spray Drying Machine Energy Saving

Description
Voltage: 110V/220V/380V/415V/480V Hertz: 50HZ, 60HZ
Material: SUS304/SUS316L Installation Power: 2.2KW-255KW
Drying Temperature: 120-350℃ Weight: 0.25Ton-40Ton
Heating Resource: Steam/Electric/Gas/Diesel Drying Efficiency: 70%
Way To Control: Button/Touch Screen/Remote Special Design: Explosion Resistance/Low Temperature Drying
Loading Capcity: 5KGS/H-10000KGS/H
High Light:

Spin Flash Spray Drying Machine

,

10000KG/H Spray Drying Machine

,

hot air spin flash dryer

Features of Energy Saving Environmental Friendly Food Drying Spin Flash Air Dryer Machine

♦ There are many kinds feeding equipment for choosing, and feeding is continue and static.
♦ At the bottom of drier, where is high temperature area, heat sensitivity raw material cannot contact with heat surface directly, therefore it solves the carbonized and changed color problems of heat sensitivity raw material.
♦ There are air pressure equipment and shaft equipment, so can longer life of machine.
♦ There is special equipment for sharing wind, and raising the amount of hot air.
♦ There are rotational flow pieces inside the drying chamber. It is used to control the moisture and granule of raw material to needed level.
♦ The density will be added in the machine.
♦ Because gas speed at circle inside the drying chamber is high and the staying time of raw material is short, high efficiency and quick speed can be realized. It is possible for small equipment to carry out large-scale production.

Principle of Energy Saving Environmental Friendly Food Drying Spin Flash Air Dryer Machine

♦ Hot air enters into stirring and crushing and drying chamber from the bottom of drier with suitable atomizing speed .It exerts strong shearing, blowing, floating and rotating effect to raw material. Therefore raw material is granulated through centrifuge, shearing, impacting and friction effect. It strengthens the process of heat exchange. At the bottom of drier, the large and damp granule is crushed under the action of stirrer and the granule that is small in partial and contain less moisture will lift accompanied with revolving air stream. During the period of lift, it is dried further. Because gas and solid two phases flow in rotating and the inertia of solid phases is more than that of gas and the relative velocity between solid and gas phase is large, so it strengthens the process of heat exchange. Therefore the machine has strong drying capacity.


10000KG/H Spin Flash Spray Drying Machine Energy Saving 0
10000KG/H Spin Flash Spray Drying Machine Energy Saving 1


Technical Parameters of Energy Saving Environmental Friendly Food Drying Spin Flash Air Dryer Machine
10000KG/H Spin Flash Spray Drying Machine Energy Saving 2


Picture of Energy Saving Environmental Friendly Food Drying Spin Flash Air Dryer Machine
10000KG/H Spin Flash Spray Drying Machine Energy Saving 3



After Sell Service

10000KG/H Spin Flash Spray Drying Machine Energy Saving 4


Service before sell:
----Provide relative technical data for help equipment selection
----Running pilot test
----Offering advice for equipment selection, material analysis
----Provide flow chart, basic drawing
----Provide technical design
Service in sell:
----Provide factory layout according to contract
----Manufacturing ordered equipment according to the related standard
---- A presentation report of manufacturing situation will be offered every 15days
---- Tracking and supervising in whole manufacturing and transporting period according to the contract requirement
---- Photo of wooden case will be offered, wooden case with standard shipping marks.
---- Photo of freight loading will be offered.
---- A record of detailed delivery list will be offered
---- A record of detailed freight loading list will be offered
---- All of wooden case will be marked serial number, all of attachments will be marked serial number, convenient for client's clearing
Service after sell:
----Send service engineer for help instruct installation.
----Send service engineer for running test at site and training the operator
----Help client for maintenance and repair
----Provide one year spare part
----Quality warranty for two years after sell




Packing & Delivery

10000KG/H Spin Flash Spray Drying Machine Energy Saving 5
10000KG/H Spin Flash Spray Drying Machine Energy Saving 6
10000KG/H Spin Flash Spray Drying Machine Energy Saving 7
