Anti Sticking Milk Spray Drying Machine Dehumidification Air Cooling

Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling
Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling

Large Image :  Anti Sticking Milk Spray Drying Machine Dehumidification Air Cooling

Product Details:
Place of Origin: China
Brand Name: WELLDONE
Certification: CE, ISO 9001: 2008, ISO 10004
Model Number: LPG-(5-2000)
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: Wooden Case + Plastic Film + Steel Frame
Delivery Time: 30-90Working Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10Sets/Months

Anti Sticking Milk Spray Drying Machine Dehumidification Air Cooling

Description
Voltage: 110V/220V/380V/415V/480V Hertz: 50HZ, 60HZ
Material: SUS304/SUS316L Installation Power: 2.2KW-255KW
Drying Temperature: 120-350℃ Weight: 0.25Ton-40Ton
Heating Resource: Steam/Electric/Gas/Diesel Drying Efficiency: 70%
Way To Control: Button/Touch Screen/Remote Special Design: Explosion Resistance/Low Temperature Drying
Loading Capcity: 5KGS/H-10000KGS/H
High Light:

anti sticking Spray Drying Machine

,

Dehumidification Spray Drying Machine

,

Dehumidification milk spray dryer machine

Advanges of Environmental Friendly Fast Drying Speed Industrial Spray Dryer

Quick drying of thermal-sensitive material have troubled R&D staffs for years.Ordinary drying equipment has heavy impact on material property or structure,featuring long time in chilling and drying,low in efficiency,being lump after drying with two-step grinding needed.Given such factors as strong thermal-sensitivity,low aridity,low softening point and strong moisture absorption on materials in industry of traditional Chinese medicine,food and biological material,we developed a new type of spray dryer and the corresponding process through continuous effortsof R&D staffs.



Features of Environmental Friendly Fast Drying Speed Industrial Spray Dryer

1) Drying in quick speed.
2) Product in good quality.
3) Good performance in dispersity,liquidity and solubility.
4) Simplified process and convenient operation.
5) Cooling jacket system between drying chamber wall and roof against sticking in chamber wall.
6) Air rotation sweep system inside drying chamber wall ,to eliminate or reduce possibility of sticking in chamber wall.
7) Dehumidification air cooling technology applied in powered-collection system to protect product form lump and easy for package.
8) Conform to GMP national standard,air cleanness in contact with material up to 100000 grade and mirror-like inner wall in contact with material
.



Application of Environmental Friendly Fast Drying Speed Industrial Spray Dryer

This drying process has been proved very convenient and effcient for thermal-sensitive materialsuch as extract of animals and plants,fermentation broth,bacterial cells,enzyems,and other thermal-sensitive ingredients,which are widely applied in the fields of pharmaceuticals,foods and Chemical Factoty.This unique spray dryer has got a good reputation domestically and overseas.







Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling 0

Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling 1









Technical Parameters of Environmental Friendly Fast Drying Speed Industrial Spray Dryer

Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling 2





Picture of Environmental Friendly Fast Drying Speed Industrial Spray Dryer in Working

Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling 3







After Sell Service

Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling 4



Service before sell:

----Provide relative technical data for help equipment selection

----Running pilot test

----Offering advice for equipment selection, material analysis

----Provide flow chart, basic drawing

----Provide technical design



Service in sell:

----Provide factory layout according to contract

----Manufacturing ordered equipment according to the related standard

---- A presentation report of manufacturing situation will be offered every 15days

---- Tracking and supervising in whole manufacturing and transporting period according to the contract requirement

---- Photo of wooden case will be offered, wooden case with standard shipping marks.

---- Photo of freight loading will be offered.

---- A record of detailed delivery list will be offered

---- A record of detailed freight loading list will be offered

---- All of wooden case will be marked serial number, all of attachments will be marked serial number, convenient for client's clearing



Service after sell:

----Send service engineer for help instruct installation.

----Send service engineer for running test at site and training the operator

----Help client for maintenance and repair

----Provide one year spare part

----Quality warranty for two years after sell





Packing & Delivery

Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling 5

Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling 6

Anti Sticking Milk Spray Drying Machine Dehumidification  Air Cooling 7
