Product Description:
One of the key features of this spray dryer is its ability to produce products with excellent uniformity. Products that come from the spray dryer have very good uniformity, solubility, fluidity and purity. This makes it an ideal choice for industries that require high-quality products with consistent properties.
The Spray Drying Machine is designed to be explosion-resistant, which is an important safety feature in industrial settings. Additionally, it is capable of low-temperature drying, which makes it well-suited for use with heat-sensitive materials.
The drying temperature of the Spray Drying Machine ranges from 120-350℃, which means it can be used with a wide range of materials. This flexibility makes it a popular choice for manufacturers who need to process a variety of materials.
The installation power required for the Spray Drying Machine is 55KW, which is a modest amount of power for an industrial spray dryer. This makes it an energy-efficient choice for manufacturers who are looking to reduce their energy consumption.
Overall, the Spray Drying Machine is an excellent choice for industrial spray dryer working. It is manufactured by a reputable industrial spray dryer manufacturer and is designed to meet the needs of a wide range of industries. Whether you need to process heat-sensitive materials or require high-quality, consistent products, the Spray Drying Machine is an excellent choice.
Features:
-
Product Name: Spray Drying Machine
-
Drying Temperature: 120-350℃
-
Drying Efficiency: 70%
-
Material: SUS316L
-
Special Design: Explosion Resistance/Low Temperature Drying
-
Way To Control: Button/Touch Screen/Remote
As an industrial spray dryer manufacturer, our Spray Drying Machine is perfect for drying powder. Our spray dryer manufacturers have designed this machine to ensure explosion resistance and low temperature drying capabilities.
Technical Parameters:
|
Loading Capacity
|
5KGS/H-10000KGS/H
|
|
Product Category
|
Spray Drying Machine
|
|
Drying Efficiency
|
70%
|
|
Product Uniformity
|
Product comes from spray dryer has very good uniformity, solubility, fluidity and purity.
|
|
Principle
|
Hot air enters into dryer in spiral form under the function of air distributor after being filtered and heated. By passing through high-speed rotary atomizer on top of tower, the liquid raw material will be sprayed into the extremely fine mist beads. Through the very short time of contacting with hot air, the liquid can be dried into final solid powder products.
|
|
High Speed Drying
|
After liquid raw material being sprayed, its' surface area will be increased greatly. With higher drying efficiency, 95%-98% of water could be evaporated in a few seconds.
|
|
Hertz
|
50HZ
|
|
Way To Control
|
Button/Touch Screen/Remote
|
|
Simple Production Procedures
|
The production procedures are simple, the operation and control are easy. Liquid with the moisture contents ranges 40-60% (for some special materials, the moisture content is available at 90%) can be dried into the powder in one time.
|
|
After Sell Service
|
Provide relative technical data for help equipment selection, running pilot test, offering advice for equipment selection, material analysis, provide flow chart, basic drawing, provide technical design, provide factory layout according to contract, manufacturing ordered equipment according to the related standard, a presentation report of manufacturing situation will be offered every 15days, tracking and supervising in whole manufacturing and transporting period according to the contract requirement, photo of wooden case will be offered, wooden case with standard shipping marks, photo of freight loading will be offered, a record of detailed delivery list will be offered, a record of detailed freight loading list will be offered, all of wooden case will be marked serial number, all of attachments will be marked serial number, convenient for client's clearing, send service engineer for help instruct installation, send service engineer for running test at site and training the operator, help client for maintenance and repair, provide one year spare part, quality warranty for two years after sell.
|
Applications:
The spray dryer function of this machine is to dry liquid raw material in a few seconds with higher drying efficiency. It can evaporate 95%-98% of water from the liquid in a few seconds. This energy-saving machine is designed to dry liquid with a moisture content range of 40-60% in one time. For some special materials, the moisture content is available at 90%. This simple production procedure of the machine makes it easy to operate and control.
This spray drying machine is an ideal choice for powder production. It can be used in various industries, including food, chemical, pharmaceutical, and other industries. The machine has a weight of 40 tons and is suitable for large-scale production.
Support and Services:
The Spray Drying Machine is a high-performance machine designed for the production of dry powder from a liquid or slurry by rapidly drying with hot gas. To ensure optimal performance, our technical support and services team is available to assist with any issues that may arise. Our services include:
-
Installation and commissioning
-
Preventive maintenance
-
On-site training
-
Remote technical support
-
Repairs and spare parts
-
Process optimization
Our team of experienced technicians is dedicated to providing timely and effective support to maximize the uptime and efficiency of your Spray Drying Machine.
Packing and Shipping:
Product Packaging:
-
The Spray Drying Machine will be securely packed in a sturdy wooden crate.
-
The machine will be wrapped in protective foam to prevent any damage during transportation.
-
All necessary accessories and components will be included in the package.
Shipping:
-
The Spray Drying Machine will be shipped via a reputable courier service.
-
The shipping cost will be calculated based on the destination and weight of the package.
-
Customers will be provided with a tracking number to monitor the delivery status of their package.
-
Delivery times may vary depending on the destination and any customs procedures.
FAQ:
Q: What is the brand name of this Spray Drying Machine?
A: The brand name of this Spray Drying Machine is WELLDONE.
Q: What is the model number of this Spray Drying Machine?
A: The model number of this Spray Drying Machine is LPG-(5-2000).
Q: What certifications does this Spray Drying Machine have?
A: This Spray Drying Machine has CE, ISO 9001: 2008, and ISO 10004 certifications.
Q: Where is this Spray Drying Machine made?
A: This Spray Drying Machine is made in China.
Q: What is the minimum order quantity for this Spray Drying Machine?
A: The minimum order quantity for this Spray Drying Machine is 1 Set.
Q: What is the price of this Spray Drying Machine?
A: The price of this Spray Drying Machine is negotiable.
Q: What are the payment terms for this Spray Drying Machine?
A: The payment terms for this Spray Drying Machine include L/C, D/A, D/P, T/T, Western Union, and MoneyGram.
Q: What is the supply ability of this Spray Drying Machine?
A: The supply ability of this Spray Drying Machine is 10 Sets per month.
Q: What is the delivery time for this Spray Drying Machine?
A: The delivery time for this Spray Drying Machine is between 30-90 working days.
Q: What are the packaging details for this Spray Drying Machine?
A: The packaging details for this Spray Drying Machine include a wooden case, plastic film, and steel frame.
