8000KGS/Batch Titanium Minced Meat hollow paddle dryer

Large Image : 8000KGS/Batch Titanium Minced Meat hollow paddle dryer

Product Details:

Place of Origin:	China
Brand Name:	WELLDONE
Certification:	CE, ISO 9001: 2008, ISO 10004
Model Number:	PZG-(500-12000)

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	11000 USD to 200000 USD
Packaging Details:	Wooden Case + Plastic Film + Steel Frame
Delivery Time:	30-60Working Days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	10Sets/Months

Contact Now

8000KGS/Batch Titanium Minced Meat hollow paddle dryer

Description

Voltage:	110V/220V/380V/415V/480V	Hertz:	50HZ, 60HZ
Material:	CS/SUS304/SUS316L/Titanium	Installation Power:	5.5KW-85KW
Drying Temperature:	50-150℃	Weight:	0.8Ton-40Ton
Heating Resource:	Steam/Thermal Oil/Hot Water	Drying Efficiency:	80%
Way To Control:	Button/Touch Screen/Remote	Special Design:	Explosion Resistance/Low Temperature Drying
Loading Capcity:	150KGS/Batch-8000KGS/Batch
Highlight:	Titanium hollow paddle dryer , 8000 KGS/Batch hollow paddle dryer , Minced Meat paddle dryer machine

Description of Energy Saving Fast Drying Speed Minced Meat Hollow Paddle Dryer

The dryer is a machine used to heat treat powders, granulates, filter cakes and pasty products in a full-continuous process.

These processes vary from drying, cooling, crystallizing and calcimining to melting, evaporating, solvents, sterilizing, etc

The paddle dryer has a heated through containing rotating heated paddle shafts. The product is fed into the front of the machine. The through is oriented at a small angle of inclination, placed slightly in unloading position. The product moves to the outlet as a result of gravity. The paddles do not have a transport function.

They are designed for maximum heat transfer. At the outlet side, the product moves out of the machine via the overflow unit.

Features of Energy Saving Fast Drying Speed Minced Meat Hollow Paddle Dryer

Compact struture, small occupied space.

High degree of heat conducting, best heat effeat, attain 80-90%,saving energy equipment.

Low speed, 10-40 Rpm, reduce the damage of the particles and flaky material.

Wide range of application, easy to operate, drying time is adjustable.

Attached equipment is simple, low investment.

Multi-usage, such as drying, cooling, gas recovery, responding, heating and so on.

Application of Energy Saving Fast Drying Speed Minced Meat Hollow Paddle Dryer

1. inorganic chemical industry
calcium nitrate, calcium sulfate, calcium paper, calcium carbonate, magnesium hydroxide, carbon black, iron black, iron oxide red, soda, soda ash, etc.;

2, organic chemical industry

dyestuff, industrial plastic, polystyrene, polypropylene, high density polyethylene, polypropylene, etc.;

3, smelting industry

tar, sulfur, nickel ore concentrate ore concentrate removing phenol, etc.;

4, food, medical industry

starch, pharmaceutical, salt, protein, etc.;

5, other: sludge, waste residue, chicken feed, lees, etc.;

8000KGS/Batch Titanium Minced Meat hollow paddle dryer 2

Technical Parameters of Energy Saving Fast Drying Speed Minced Meat Hollow Paddle Dryer

8000KGS/Batch Titanium Minced Meat hollow paddle dryer 3

8000KGS/Batch Titanium Minced Meat hollow paddle dryer 4

Picture of Energy Saving Fast Drying Speed Minced Meat Hollow Paddle Dryer in Working

8000KGS/Batch Titanium Minced Meat hollow paddle dryer 5

After Sell Service

8000KGS/Batch Titanium Minced Meat hollow paddle dryer 6

Service before sell:

----Provide relative technical data for help equipment selection

----Running pilot test

----Offering advice for equipment selection, material analysis

----Provide flow chart, basic drawing

----Provide technical design

Service in sell:

----Provide factory layout according to contract

----Manufacturing ordered equipment according to the related standard

---- A presentation report of manufacturing situation will be offered every 15days

---- Tracking and supervising in whole manufacturing and transporting period according to the contract requirement

---- Photo of wooden case will be offered, wooden case with standard shipping marks.

---- Photo of freight loading will be offered.

---- A record of detailed delivery list will be offered

---- A record of detailed freight loading list will be offered

---- All of wooden case will be marked serial number, all of attachments will be marked serial number, convenient for client's clearing

Service after sell:

----Send service engineer for help instruct installation.

----Send service engineer for running test at site and training the operator

----Help client for maintenance and repair

----Provide one year spare part

----Quality warranty for two years after sell

Packing & Delivery

8000KGS/Batch Titanium Minced Meat hollow paddle dryer 10

8000KGS/Batch Titanium Minced Meat hollow paddle dryer 11
