100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants
100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants
100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants

Large Image :  100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants

Product Details:
Place of Origin: China
Brand Name: WELLDONE
Certification: CE, ISO 9001: 2008, ISO 10004
Model Number: SZG-(100-6000)
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: Wooden Case + Plastic Film + Steel Frame
Delivery Time: 30-60Working Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10Sets/Months
Contact Now

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants

Description
Voltage: 110V/220V/380V/415V/480V Hertz: 50HZ, 60HZ
Material: SUS304/SUS316L Installation Power: 1.5KW-55KW
Drying Temperature: 50-150℃ Weight: 0.5Ton-40Ton
Heating Resource: Steam/Thermal Oil/Hot Water Drying Efficiency: 80%
Way To Control: Button/Touch Screen/Remote Special Design: Explosion Resistance/Low Temperature Drying
Loading Capcity: 25KGS/Batch-3000KGS/Batch
Highlight:

SUS316L Vacuum Rotary Dryer

,

100L Vacuum Rotary Dryer

,

Food Processing Vacuum Rotary Dryer

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants


100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 0


Features of 100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants

When oil is used to heat, automatic constant twmperature control will running. It can be used for drying iology products and mine. Its temperature of operation can be adjusted from 20-160 °c and within ±2°c

Compared with ordinal drier, its heat efficiency will be over 2 times

Model SZG-100 SZG-350 SZG-500 SZG-750 SZG-1000 SZG-1500 SZG-2000
Total volume (L) 100 350 500 750 1000 1500 2000
Loading volume (L) ≤50 ≤ 175 ≤ 250 ≤ 375 ≤ 500 ≤ 750 ≤ 1000
Rotary speed (r/min) 3-13
Motor power (kw) 0.75 1.1 1.5 2 3 3 4
Rotary height (m) 1.75 2.1 2.25 2.49 2.8 2.94 2.99
Tank inner pressure (Mpa) -0.1-0.15
Clip set pressure (Mpa) ≤ 0.3
Working temp.(°C) Inner tank ≤ 85 Clip set ≤ 140
Heating media Steam, Hot water, Heat transfer oil
Weight (kg) 800 1100 1200 1500 2800 3300 3600
Floor area (L*W) 2160*800 2260*800 2350*800 2550*1000 2860*1300 3260*1400 3760*1800

Principle of 100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants

1. heat source pass through the sealed jacket

2. the heat will be transmitted to the raw material to be dried through inner shell

3. under driving of power, the tank is rotated slowly and the raw material inside it is mixed continuously. then the purpose of reinforced drying can realized

4. the material is at a vacuum state, the drop of steam pressure makes the moisture at the surface of raw material become saturation and will evaporate

5. the solvent will be discharged through vacuum pump

6. the inner moisture of raw material will infiltrate, evaporate and discharge continuously. these three processes are carried continuously and the purpose of drying can be realized within a short time



Main Application of 100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants

It is suitable for the raw materials that need to concentrate, mix and dry at low temperature(eg. biochemistry products in chemical, pharmaceutical and foodstuff industries).

1. materials that are easy to oxidize

2. materials that are easy to volatilize

3. materials that having strong heat sensitive or toxic

4. materials that should not destroy its crystal in drying





100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 1

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 2

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 3







Technical Parameters of 100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 4





Picture of 100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 5

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 6

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 7

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 8







After Sell Service

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 9



Service before sell:

----Provide relative technical data for help equipment selection

----Running pilot test

----Offering advice for equipment selection, material analysis

----Provide flow chart, basic drawing

----Provide technical design



Service in sell:

----Provide factory layout according to contract

----Manufacturing ordered equipment according to the related standard

---- A presentation report of manufacturing situation will be offered every 15days

---- Tracking and supervising in whole manufacturing and transporting period according to the contract requirement

---- Photo of wooden case will be offered, wooden case with standard shipping marks.

---- Photo of freight loading will be offered.

---- A record of detailed delivery list will be offered

---- A record of detailed freight loading list will be offered

---- All of wooden case will be marked serial number, all of attachments will be marked serial number, convenient for client's clearing



Service after sell:

----Send service engineer for help instruct installation.

----Send service engineer for running test at site and training the operator

----Help client for maintenance and repair

----Provide one year spare part

----Quality warranty for two years after sell





Packing & Delivery

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 10

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 11

100L Double Cone SUS316L Vacuum Rotary Dryer Steam Generator Condenser Food Processing Manufacturing Plants 12
